Product Description
Keep your edge with the Aura Pro X2 1TB NVMe SSD Upgrade Kit from OWC / Other World Computing. Designed for installation in select September 2013 and later 27" & 21.5" iMacs, this internal flash/SSD drive comes complete with tools, display tape, and installation components. It features a PCIe 3.1 x4, NVMe 1.3 interface and a custom blade form factor, and uses 3D TLC synchronous NAND flash memory with advanced SLC caching to deliver sequential data read and write speeds of up to 3230 and 2445 MB/s respectively--up to twice as fast as the factory-installed drives. Additionally, the Aura Pro X2 is calibrated to consume only 5.7W during operation and to run cool._x005F_x000Dx005F_x000D_The Aura Pro X2 is designed for macOS High Sierra 10.13 and later, taking full advantage of the advanced features of APFS, including strong encryption, copy-on-write metadata, space sharing, cloning for files and directories, snapshots, fast directory sizing, atomic safe-save primitives, and improved file system fundamentals. The drive reserves 7% of its overall capacity as free space to perform background maintenance tasks that optimize the health, performance, and endurance of your flash drive.- Includes: (1) OWC Aura Pro X2 Solid-State Drive; (2) OWC 2-1/4" Suction Cup Blue; (1) OWC Torx T10S Driver; (1) OWC Torx T8S Driver; (1) OWC Torx T5 Driver; (1) OWC Phillips PH00 Driver; (1) OWC Torx T25 Hex Key; (1) NewerTech Pry Tool; (1) OWC iMac Cutting Wheel for Display; (1) OWC Blue Microfiber Screen Cleaning Wipe; (1) Apple iMac A1418 21.5" Display Tape Set; (1) Apple iMac A1419 27" Display Tape Set; 5 Year OWC Limited Warranty
- Standard Mechanism: (1) 1.0TB OWC Aura Pro X2 Solid-State Drive; *OWC reserves the right to replace or upgrade to equivalent or better components.
- Capacity: 960GB Useable Capacity; Total Flash Memory Components: 1024GB; 64GB Allocated to real-time data redundancy and error correction
- Formatted Capacity: 894GiB
- Form Factor: Custom Blade
- Storage Interface: PCIe 3.1 x4, NVMe 1.3
- Format: Unformatted
- Controller: Silicon Motion SM2262EN Series Processor with 7% over-provisioning
- NAND Flash Components: Synchronous Triple-Level Cell (TLC) 3D NAND Flash
- Native Command Queuing (NCQ): Up to 32 simultaneous commands
- Sequential Read (Max): Up to 3230 MB/s
- Sequential Write (Max): Up to 2445 MB/s
- Average Access Time: <0.1 ms
- MTBF (Mean Time Between Failures): 1,500,000 hours
- TRIM Support: OS Dependent
- Error Correction: Built-in ECC
- Endurance: 450TB total bytes written (TBW), equal to 177 GB per day for 7 years
- Mac OS Compatibility: macOS 10.13 High Sierra; macOS 10.14 Mojave; macOS 10.15 Catalina; macOS 11.x Big Sur; macOS 12.x Monterey; macOS 13.x Ventura
- Other Requirements: The host computer must be updated to macOS 10.13 or later before installing this drive.
- Read Mode (Max): Up to 5.7 Watts
- Write Mode (Max): Up to 5.7 Watts
- Seek Mode (Max): Up to 5.7 Watts
- Idle Mode (Max): Up to 0.3 Watts
- Dimensions: Height: 0.3 cm (0.1 in); Length: 8.9 cm (3.5 in); Width: 2.2 cm (0.9 in)
- Weight: 9.0 g (0.02 lbs)
- RoHS Compliant: Yes
- Ambient Temperature: Operating: 32?F to 158?F (0?C to 70?C); Non-Operating: -40?F to 185?F (-40?C to 85?C)
- Altitude: Operating: -304.8 m to 3,048.0 m (-1,000 ft to 10,000 ft); Non-Operating: -304.8 m to 12,192.0 m (-1,000 ft to 40,000 ft)
- Humidity: Operating: 5% to 95% non-condensing
- Shock: Non-Operating: 1500 G max at 0.5 ms
- Idle (Typical): 0.0 bels
- Seek (Typical): 0.0 bels
